EASY ORDER Minibike Parts

Take the guess work out of ordering Mini Bike Parts.

All of these parts fit and work together and can be ordered in any combination to build or repair a go kart.

Used by many USA Manufacturers since 1960 including Azusa, Manco, Yerf-Dog, Taco, Rupp, Kenbar, Kartco and more.

*click on the Part Numbers below to display the Spec Sheet for each part

PART#	DESCRIPTION	QTY Needed
1144	Wheel, 5" Front/Rear with 5/8" Bearings and Hardware	2
8356	Wheel Spacer, Front 5/8" ID x 1-7/8"	2
8357	Wheel Spacer, Rear 5/8" ID x 2-1/4"	2
8121-9	Front Axle, 5/8" x 9"	1
8210-10	Rear Axle, 5/8" x 10"	1
8524	Axle Nut, 5/8"	4
7037	Sawtooth Tire, Front 410/350 x 5	1
7033	Knobby Tire, Front/Rear 410/350 x 5	1
7132	Innertube 410/350 x 5	2
8206	Wheel Bearings 5/8" 1-3/8" OD	4
2208	Brake Assembly 4-1/2" x 5/8" Bore	1
2217	Sprocket/Drum, 60 Tooth #35 chain size	1
2352	Throttle Control, for 7/8" Handlebars, with 54" Cable	1
1632	Deluxe Padded Seat, 12" and Hardware	1
4008	Chain #35 and Masterlink	1
1721	Kill Button Switch, 36" Wire	1
1810	Chain Deflector, Chrome	1
3545	Minibike Frame & Fork Kit	1
3548	Minibike Frame	1
3546	Minibike Fork	1
8472	Fork Bolt	1
